CC-111
Corner Cleaner



The CC-111 cleans corners of PVC profiles after welding. With a fully electronic, pneumatic system, it cleans the upper and lower corners simultaneously. The Control Panel is ergonomically designed to easily be moved to all angles of the machine. Includes set of scraping blades, saw and milling cutters.

  • Fast, high precision, 2-axis servo motor controls
  • Automatic Frame and Sash profile recognition system
  • All unit parameters can be set independently according to the frames
  • Cleans the lower and upper surfaces with two separate cleaning units, working independently of each other
  • Ability to easily adjust the progress rates via the screen during the operation
  • Wireless network connection and data transfer via USB and Automatic Backup Option
  • Ability to save different profile size and features
  • Window PC, industrial with 19’’ LCD Touch Screen colour monitor
Technical Specifications
Standard Voltage 220 V
Frequency 50-60 Hz
h max, h min, a min 170mm, 40mm 120mm
Air Pressure 6-8 Bar
Sawblade D: 250mm d: 30/32mm
Rotation 3000 RPM
Machine Dimensions 927mm x 1429mm x 2898mm
Machine Weight 800 kilo
